UN-TS01 1080P Face Recognition Body Temperature Infrared Thermal Camera
*Thermal and optical Bi-spectrum with facial recognition
* Built-in high accuracy thermal infrared module,temperature detection range 35℃~42℃,precision±0.3℃
* Support real-time display and overlay of human body temperature OSD
* H.265+ /H.265 / H.264 / MJPEGH.265/H.264, 2MP(1920×1080)
* Face detection speed:<300ms
* Face Capacity: Max. 50,000 face storage
*8 inch LCD Touch Screen, 2MP wide-angle dual lens
* Built-in IO output or Wiegand out,easy to communicates with the third-party turnstile
| Display | 8 inch LCD | ||
| Thermal | Image Sensor | Far infrared temperature sensor | |
| Spectral Range | 8~14um | ||
| Resolution | 80×60 | ||
| Temperature Measurement Range | Range:35~42℃, | ||
| Field of View | 33° | ||
| Temperature Measurement | global and regional | ||
| Temperature Exception Alarm | High temperature limit, Low temperature limit, Regional temperature exception | ||
| Optical | Lens Length | 3.6mm, | |
| Field of View | 118° | ||
| Min. Illumination | 0.005Lux F1.2(color);0.001Lux F1.2(D/N) | ||
| WDR | ≥120dB | ||
| S/N Ratio | ≥46dB(AGC OFF) | ||
| Exposure Mode | Program(customizable shutter interval), shutter(1/5-1 / 20,000s), support for slow shutter | ||
| White Balance | Auto, indoor, outdoor, sodium lamp mode, manual | ||
| Noise Reduction | 2DNR,3DNR | ||
| Day/Night | color/B/W | ||
| Video Compression | H.265 Main Profile / H.264 High profile / M-JPEG | ||
| Max Resolution | 1920×1080@30fps | ||
| Resolution | Main Stream | 1920×1080,1280×960,1280×720,720×576 | |
| Substream | 640×480,352×288,320×240,176×144 | ||
| MJPEG | 1920×1080,1280×720,shut down | ||
| Stream | CBR,VBR( from 32Kbps to 10Mbps) | ||
| Audio Compression | G711,PCM | ||
| Character Overlay | Support channel name, date and time overlay, overlay position adjustable; character overlay | ||
| AI | Face Capacity | Max. 50,000 face | |
| Recognition Speed | <300ms | ||
| Live Detection | support | ||
| Port | Power Interface | DC12V | |
| Network Interface | 1 10M/100M Ethernet port (RJ-45) | ||
| Wiegand | 1 channel | ||
| Digital interface | 1 channel | ||
| SD card interface | Supports up to 128G | ||
| USB | 2 USB ports, 1 expandable | ||
| MIC | Built-in | ||
| Audio interface | 2ch audio output | ||
| RS485 | support | ||
| Environment | Operating Temperature | -20°C ~60°C | |
| Working Humidity | 0%-90% RH(Non-condensing) | ||
| Power | Power Consumption | 5W | |
| Physical Characteristics |
Size | 215x125x25mm | |
| Weight | <1kg | ||
